| TECHNICAL DATA | ING 65.500 C |
| MAXIMUM LOAD MOMENT | 65.500 kgm |
| MAXIMUM VERTICAL REACH (FROM GROUND) | 27,3 m |
| MAXIMUM HORIZONTAL REACH | 23,7 m |
| MAXIMUM HYDRAULIC VERTICAL REACH | 23,0 m |
| MAXIMUM HYDRAULIC HORIZONTAL REACH | 19,2 m |
| MAXIMUM INCLINATION ANGLE | 80° |
| SLEW ANGLE | CONTINUOUS |
| SLEW TORQUE | 6,2 tm |
| OIL TANK VOLUME | 265 l |
| WORKING PRESSURE | 320 bar |
| APPROXIMATE STANDARD WEIGHT* | 7200 kg |
| SPACE REQUIRED FOR ASSEMBLY | 1,8 m |
| FRONT OUTRIGGER EXTENDED | 8,0 m |
| NUMBER OF HYDRAULIC BOOMS | 7 |
| NUMBER OF MANUAL BOOMS (OPTIONAL) | 2 |
| MINIMUM PBT FOR ASSEMBLY | 23 Ton |
