| TECHNICAL DATA | ING 52.500C + FLY JIB 5H 1M | ING 52.500C + FLY JIB 4H 1M |
| MAXIMUM LIFTING CAPACITY | 52.500 kgm | 52.500 kgm |
| VERTICAL MAXIMUM REACH FROM GROUND | 30,4 m | 28,8 m |
| HORIZONTAL MAXIMUM REACH | 27,7 m | 26,0 m |
| HYDRAULIC VERTICAL MAXIMUM REACH | 28,8 m | 27,3 m |
| HYDRAULIC HORIZONTAL MAXIMUM REACH | 26,0 m | 24,5 m |
| MAXIMUM ANGLE OF INCLINATION | 75° | 75° |
| SLEWING ANGLE | 420° | 420° |
| SLEWING TORQUE | 5,6 tm | 5,6 tm |
| TANK CAPACITY | 265 l | 265 l |
| MAXIMUM OPERATING PRESSURE | 280 bar | 280 bar |
| STANDARD WEIGHT* | 6880 kg | 6800 kg |
| FITTING SPACE REQUIRED | 2,0 m | 2,0 m |
| EXTENDED FRONT STABILIZER | 8,0 m | 8,0 m |
| NUMBER OF HYDRAULIC BOOMS | 11 | 10 |
| NUMBER OF MANUAL BOOMS OPTIONAL | 1 | 1 |
| GVW FOR ASSEMBLY | 23 Ton | 23 Ton |
