| TECHNICAL DATA | ING 65.500 C + FLY JIB 5H 1M |
| MAXIMUM LOAD MOMENT | 65.500 kgm |
| MAXIMUM VERTICAL REACH (FROM GROUND) | 33,2 m |
| MAXIMUM HORIZONTAL REACH | 29,7 m |
| MAXIMUM HYDRAULIC VERTICAL REACH | 31,6 m |
| MAXIMUM HYDRAULIC HORIZONTAL REACH | 28,1 m |
| MAXIMUM INCLINATION ANGLE | 80° |
| SLEW ANGLE | CONTINUOUS |
| SLEW TORQUE | 6,2 tm |
| OIL TANK VOLUME | 265 l |
| WORKING PRESSURE | 320 bar |
| APPROXIMATE STANDARD WEIGHT* | 8000 kg |
| SPACE REQUIRED FOR ASSEMBLY | 2,0 m |
| FRONT OUTRIGGER EXTENDED | 8,0 m |
| NUMBER OF HYDRAULIC BOOMS | 11 |
| NUMBER OF MANUAL BOOMS (OPTIONAL) | 1 |
| MINIMUM PBT FOR ASSEMBLY | 23 Ton |
