| TECHNICAL DATA | ING 12.500 |
| MAXIMUM LIFTING CAPACITY | 12.500 kgm |
| VERTICAL MAXIMUM REACH FROM GROUND | 16,7 m |
| HORIZONTAL MAXIMUM REACH | 13,9 m |
| HYDRAULIC VERTICAL MAXIMUM REACH | 11,7 m |
| HYDRAULIC HORIZONTAL MAXIMUM REACH | 8,8 m |
| MAXIMUM ANGLE OF INCLINATION | 80° |
| SLEWING ANGLE | 360° |
| SLEWING TORQUE | 2,0 tm |
| TANK CAPACITY | 100 l |
| MAXIMUM OPERATING PRESSURE | 210 bar |
| STANDARD WEIGHT* | 1815 kg |
| FITTING SPACE REQUIRED | 0,9 m |
| EXTENDED FRONT STABILIZER | 4,4 m |
| NUMBER OF HYDRAULIC BOOMS | 3 |
| NUMBER OF MANUAL BOOMS OPTIONAL | 3 |
| GVW FOR ASSEMBLY | 10 Ton |
